Quick Details

  • Place of Origin: China (Mainland)
  • Brand Name: CHADI
  • Model Number: CDS-L
  • Phase: Single Phase
  • Protection: IP20
  • Output Voltage: Single phase 220V±1%
  • Type: On-line
  • Application: Security / Monitoring / Alarm
  • Main Features: 3-proof technique
  • Main Features 2: comprehenvise pretection
  • Main Features 3: DSP full digitalized control
  • Main Features 4: enviromental protection and energy-saving
  • Main Features 5: friendly computer-human interface
  • Main Features 6: Superior loading characteristics
  • Main Features 7: High power dynamic performance
  • Main Features 8: Auto re-start function
  • Main Features 9: 3-phases control seperately
  • Main Features 10: super wide input voltage range

Packaging & Delivery

Packaging Details: Carton/Wooden case/pallet
Delivery Detail: 1 day

Specifications

Line Interactive 2K Ups Power Plug Socket
1.high frequency ups
2.True double-conversion

Line Interactive 2K Ups Power Plug Socket

Product Description

MODELCDP-2KCDP-3KCDP-5KCDP-6K
Rated power2KVA/1.6KW3KVA/2.4KW5KVA/4KW6KVA/4.8KW
INPUT
Rated voltageSingle phase 81-145 VAC / 162-290 VAC
Frequency60/50 Hz (Auto sensing)
Max power3KVA4.5KVA7.5KVA9KVA
OUTPUT
Rated voltageSingle phase 220V±1%
Frequency50Hz±0.5% / 50Hz±0.5%
Harmonic DistortionTHD ≤3% for linear loads; THD ≤5% for non-linear loads
Overloading capacitylast 10 mins for 120% overload 120%
Current Crest Ratio3:1
BATTERY
Rated voltage192Vdc
Battery type12V sealed maintenance-free battery
Battery Number16 nos.
Back-up time(min)13865
Charging time9 hours recover to 90% capacity
System
Transfer timeAC←→battery 0 ms;AC←→bypass < 1 ms
Ingress ProtectionIP20
Conversion Efficiency≥85%(full loading)
noise<50dB (1 meter)<53dB (1 meter)
ENVIRONMENT
temperature0℃~45℃
Humidity0~95% RH,non-condensing
altitude<1500m
Size
W×D×H(mm)260×620×625
Weight
N. weight (kg)758095100
